RF testing for car-to-car data comms

To ensure safety-related data is received even under poor conditions, radio systems must adhere to minimum standards and be verified using RF tests.

Road safety has improved steadily as a result of many inventions. Mechanical systems such as safety belts and airbags, as well as electronic safety equipment such as ABS and ESP, have decreased the number of accidents and their consequences in the past decades.

In order to further reduce the number of accidents, new technologies are needed. Critical traffic situations can be detected before they occur through the wireless exchange of information between vehicles (V2V communications), as well as with the traffic infrastructure and all traffic participants (V2X communications).

For example, all vehicles that drive through a crossing can exchange information about speed and direction. This makes it possible to detect potential collisions, issue appropriate warnings and autonomously initiate early countermeasures.

However, this scenario can only become reality if there is a reliable wireless exchange of information between the vehicles, even under poor transmit conditions and without line of sight.

If a single piece of information is missed, one or more of the vehicles will gain an inaccurate view of the actual situation, conceivably with deadly consequences.

Possible interference

Wireless communications systems can be affected by different types of interference. Many of these are known collectively as fading. This includes shadowing and interference caused by physical effects such as scattering, diffraction, refraction and reflection, which cause multipath propagation of the signal (Figure 1).

Figure 1: Example of fading due to multipath propagation without a line-of-sight path. Source: Rohde & Schwarz.

In other words, multiple versions of the same signal are received at the antenna at different times and with different signal levels and interference. Superpositioning of the individual signals at the receive antenna can distort, attenuate or even cancel out the received signal.

Traffic participants are also continuously moving, which adds a time variant to the fading scenario. All receivers inside vehicles are confronted with continually changing conditions and signal quality. Safety-critical applications must function reliably under these conditions.

If a receiver cannot handle fading with the time variant, it will not be able to detect and process the received signal at the antenna. Strong coding and specialised protocols cannot compensate for the loss of the receive signal. Safety-relevant information is lost.

This can represent a considerable safety risk, especially when drivers have come to rely on warnings from a V2X system and do not expect it to fail.

Testing physical transmission

To minimise the safety risk arising from poor transmit conditions, the RF transmitters and receivers found in onboard units (OBU) and roadside units (RSU) of communications systems must exhibit certain characteristics. Developers and users wanting to integrate V2X components into their system can use RF tests to verify these requirements.

The two lowest layers of the OSI model (Figure 2) factor into these tests because they are responsible for the physical transmission of the data message:

• The physical layer is responsible for the physical transport of the data via a transmission medium. In the case of V2X communications, data is wirelessly transmitted via the air interface. This layer uses specific modulation modes, carrier frequencies and bit rates. Often the quality of the channel over which the data is transmitted is also taken into consideration.
• The data link layer is made up of two components: the MAC layer and the LLC layer. The medium access control (MAC) layer regulates access to the transmission medium for multiple subscribers. This is relevant for RF measurements. The logical link control (LLC) layer handles tasks such as error detection and correction at the protocol level.

Figure 2: The OSI model. The Open Systems Interconnection (OSI) model was standardised as a reference model in order to permit data message transmission across a wide variety of technical systems. It combines the various tasks and protocols for a network into layers. The two lowest layers are the physical layer for the physical transmission of data messages (eg, via a copper cable, a fibre-optic cable or a radio frequency) and the data link layer, consisting of the medium access control (MAC) layer and the logical link control (LLC) layer.

In contrast, tests at the protocol level, ie, from the LLC layer up to the application layer (Figure 2), are not suitable for verifying RF characteristics. These tests check that the bitstream, which is generated in the LLC layer from the received signal, is processed correctly. The RF signal at the receive antenna is ignored.

As a result, all tests at the protocol level rely on one important prerequisite — that the signal with the message has been received at the vehicle antenna and converted into a bitstream. It is acceptable for the bitstream to contain bit errors, but only as many as can be corrected using channel coding.

For error-free processing of the bitstream, the message must appear in the application layer precisely as it was received at the OBU antenna. This triggers additional actions, such as a warning message on the display or automatic braking.

The RF module (ie, the MAC layer and the physical layer) in the OBU must therefore meet certain minimum requirements, eg, with respect to the power and frequency accuracy and the packet error rate (PER).

In addition, the transmitted signal must not interfere with any of the transmission technologies in the adjacent frequencies. These characteristics can only be verified with RF tests, not protocol tests, because any interference in the transmitted signal is conducted to the receiver via the OBU’s RF module.

But how can RF module requirements be tested? And how can it be ensured that a transmitted message is actually received? A look at the mobile communications industry shows that three different types of RF tests are used to validate and certify smartphones:

• Regulatory tests check the interference that the transmit signal causes in other frequencies to ensure that it stays within a specified limit. Typically, regulatory agencies specify these limits and adherence is legally binding. These types of specifications are already available for V2X units.
• Conformity tests ascertain whether a smartphone meets the RF specifications of the technology it uses to transmit. For example, smartphones must not exceed a specified maximum packet error rate or maximum transmit power. A separate test specification often describes how to perform and evaluate these tests.
• Some mobile communications providers mandate stricter or additional tests beyond those described here to differentiate themselves from the competition by providing better transmission quality and better network reliability. Mobile devices must meet these special requirements in order to be allowed into the network.

Radio over cable

The automotive industry tests automotive components and electronic control units in the lab, on testing grounds and even on public roads. For wireless communications, this is the equivalent of field tests, offering a realistic environment for RF tests.

However, other influences such as the weather can unpredictably change the RF characteristics of the radio link. The test set-up and test sequence depend on the vehicles involved and the antenna locations, and often they can be changed only with considerable effort.

This is not practicable for testing a new device that is still in the development stage. What is needed instead are alternatives that permit realistic testing in the lab.

In wireless communications, conducted tests represent an alternative to field tests. A test system simulates the transmission channel, while a cable replaces the actual radio link. These types of RF tests can be performed for each prototype and each time the software or hardware is changed.

This approach has many advantages that make development faster and less expensive while reducing errors:

• The tests can be performed at any time and at low cost.
• The test conditions are clearly defined at all times and can be changed at any time irrespective of outside influences.
• Clearly defined test sequences, when performed under the same conditions, lead to comparable results.
• Reproducible and comparable results facilitate debugging.
• Parameters can be easily modified. This is in contrast to the great deal of effort required to modify the fading profile in a field test, for example.
• Multiple tests can be combined into test sequences and then performed automatically. This makes it possible to run long-term tests to study the reliability of a prototype.
• Certain RF tests, such as error vector magnitude (EVM) or RX sensitivity tests, only make sense as conducted tests. In a field test, uncontrolled noise and interference from external sources falsify the measurement results.

Depending on the selected scenario, channel simulation exactly simulates the physical attributes of the radio link. Today’s signal generators can also simulate the special V2X fading profiles in real time.

Field tests still make sense, especially for antenna measurements, eg, for determining antenna characteristics or for beamforming tests. Although conducted tests cannot completely replace field tests, channel simulation can simplify testing, easily and cost-effectively supporting development in the lab.

Detecting RF problems

To be able to compare the test results of the various hardware and software versions of a V2X unit, all test procedures must be clearly defined. Some countries have therefore defined test specifications for V2X systems that include test cases in four categories (see Boxes 1 and 2):

• TX in-band: The test cases in this group test the transmitter (TX) characteristics, eg, maximum and minimum transmit power, frequency accuracy and modulation accuracy.
• TX out-of-band: The unwanted transmit power outside of the allowed frequency band must not disrupt other technologies. TX out-of-band test cases therefore measure this transmit power and compare it against the allowed limit.
• RX in-band: This category tests the receiver (RX), eg, by measuring the lowest receive power at which the received signal can still be decoded or by measuring performance with fading. Figure 3 shows a screenshot of an R&S SMW200A vector signal generator with a configured V2X fading profile.
• RX out-of-band: Specialised test cases measure whether the OBU or RSU unintentionally emits transmit power in other frequency bands when the transmitter is switched off.

Figure 3: An R&S SMW signal generator showing a fading profile for V2X at 5.9 GHz. Source: Rohde & Schwarz.

Various plug tests for V2X have shown that especially the TX out-of-band and fading tests are problematic for many devices under test (Figure 4). It is possible, however, to detect these RF problems during the development phase by using appropriate test instruments.

Figure 4: TX out-of-band test. The transmit power (blue line) of an 802.11p unit exceeds the allowable limit (red line) at multiple points. The frequency range between 5855 and 5925 MHz is reserved for V2X in Europe and in the USA. Source: Rohde & Schwarz.

The RX tests can be performed with a signal generator that is capable of generating a V2X signal. A signal analyser covers the TX test cases. Depending on the dynamic range of the analyser, a filter for the V2X signal is needed to cover the broad frequency range of the out-of-band measurement.

At present, various wireless technologies are under discussion for implementing the V2X communications, in particular WLAN 802.11p, LTE and 5G, which will be available several years from now.

Regardless of which technology is used, T&M equipment manufacturers such as Rohde & Schwarz already offer the test solutions needed for V2X. For example, solutions based on the widely distributed LTE technology can be tested using the R&S TS8980 RF test system family. The available tests are continually being updated based on each LTE development, making it also suitable for V2X.

Summary

Development of wireless, automated communications between traffic participants will continue in order to improve road safety. Safety-critical messages must be transmitted reliably and quickly in every environment and every traffic situation.

Protocol tests alone are not sufficient because they do not test the circumstances under which the transmit signal arrives at the receiver. Only RF tests can ensure that the minimum physical requirements are met by OBUs and RSUs, so that lives can be saved during emergencies.
